Ross DSC 500
| Type: |
Professional Marine Transceiver |
| Frequency Range: |
RX: 156.025-163.775 MHz
TX: 156.025-159.175 MHz |
| Modes: |
FM |
| Memories: |
57 channels |
| RF Power Output: |
25W/1W (Selectable) |
| Voltage: |
13.8VDC |
| Current Drain: |
RX: 0.6 A
TX: Max 6 A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
184.1 x 82.6 x 63.8 mm |
| Weight: |
2.54 Kg |
| Manufactured: |
|
| Other: |
|
| Related Documents: |
Operating Manual (4.49 MB) |
 |
